Want an American made punching machine that is compact well designed, well built, and uncomplicated? These iron workers offer the biggest tonnage per dollar for your fabrication shop. Most of them work on the same principal with the center pulling straight down on the work. The tooling moves vertically, with no arc of a pivot arm. Most models come standard with a punching station, flat bar shear, angle iron shear, and often a coper-notcher. They operate so you can move from punch to plate shear to angle shear to notcher without always changing equipment. Many different sizes and styles of punch & die sets are available such as round, oblong slot, square, rectangle, keyhole, etc. Many kinds of optional tooling is available (coper-notcher, press brake, pipe notcher, angle notcher, rod shear, gaging table, back gauge, multi-hole punching and even radius notching). Scoll down to see our many tool options. These Ironworker machines are shipped ready to operate with hydraulic oil, blades and punches. All you have to do is connect the electricity. Optional 220 volts, single phase electrics available for most machines at $500 extra except 120 ton and 100 Deluxe. 440/480 volts costs extra. Optional Pipe & Tube Bender attachment and optional Hydraulic Shop Press attachment available.
Click to read: How to Use an Ironworker Machine
Click for our Machinery Safety webpage
Currently all our 50 Ton and larger machines include electronic stroke control and a tool box of 8 round punch sets. The Edwards design comes with ANSI compliant electrical box with lock out-tag out capability, emergency palm stop and newer safety guards.
Click for a List of our standard Ironworker Hole Punch sizes
Click for a Chart for Tonnage needed to Punch a Hole
****************************************************
Edwards 55 Ton "Jaws 4" Ironworker
Has spare hydraulic powered cavity for optional tooling on the right side
Made in USA
(Heavier and more versatile than the 50
ton machine)
Click to read every detail
about the Edwards
55 ton Ironworker Machine
THIS MACHINE IS NORMALLY IN STOCK at 3 phase and 1 phase.
Has Flat Bar Shear, Angle Shear, removable Punching Head, and on the right side any optional extra tooling can fit in the hydaulic powered jaw. The 2 versatile power stations can use any 2 sets of tooling including 2 punch heads.Scroll down to see tooling below.
- 7 " throat, 8-1/8 open height, 1-1/4 stroke
- Punch 1-1/16" diameter thru 5/8" thick steel plate
- 1-3/8 dia thru 1/2 with oversize punch option.
- Built in Bar Shear cuts 1/2 x 12", 3/8 x 14", 3/4 x 4", 1-1/8 round
- Built in Angle Shear cuts 4 x 4 x 1/4" angle or 3 x 3 x 3/8" angle or smaller
- Coper-Notcher 2 x 4 x 5/16" (option shown in photo)
- Weight: 2250 pounds
- Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase
The 55 ton is Edwards' most popular machine because it is heavy, low priced, can hold any two sets of tooling such as a punching head and pipe notcher or press brake and coper-notcher or 2 punching heads and is always in stock.
Click to see the Youtube VIDEO
We also include a tool box of 8 round punch & die sets.
Optional pipe bender, roll bender or shop press attachment available.
Click to Request Our 55 ton Lower Discount Price and info packet
Edwards 65 Ton "Jaws 5" Iron worker
Photo shows spare hydraulic powered cavity for optional tooling
Made in USA
THIS MACHINE IS NORMALLY IN STOCK at 230 Volts 3 phase 3 Weeks to build this machine with other Voltages.
- 10" throat, 8-1/8 open height, 1-3/8 stroke
- Punches 1-1/16 diameter through 3/4 thick steel plate
- 1-9/16 dia through 1/2 with oversize punch option
- Built in Plate Shear cuts 3/8 x 24", 1/2 x 14", 1" x 4", 1-1/4 round
- Built in Angle Shear cuts 5 x 5 x 1/4 angle or 4 x 4x 3/8 angle
- Built-in Coper-Notcher (2-1/2 x 6 x 3/8) included
- Spare hydraulic cavity to power extra set of tooling
- Weight: 3550 pounds.
- Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase
Scroll down to see optional tooling below.
We also include a tool box of 8 round punch & die sets.
Optional pipe bender, roll bender or shop press attachment available.
Click to Request Our 65 ton Lower Discount Price and info packet
100 Ton "Jaws 4" Edwards Ironworker
Made in USA
Has spare hydraulic cavity for optional tooling on right side
THIS MACHINE IS NORMALLY IN STOCK at 230 Volts 3 phase. 3 weeks to build this machine with other voltages.
- 10" throat, 8-5/8 open height, 1-5/8 stroke
- Punch 1-1/16" diameter through 1" thick steel plate
- 1-9/16 dia thru 3/4 with oversize punch option
- Built in Flat Bar Shear cuts 3/4 x 14, 1" x 10", 1-1/4 round
- Built in Angle Shear cuts 6 x 6 x 1/2 angle
- Coper-Notcher 2-1/2 x 6 x 1/2 (optional)
- 2 versatile cavities power any 2 sets of tooling including 2 punch & dies.
- Weight: 3700 pounds.
- Electrics: 220 Volts, 3 phase. Optional 440V or 220V, 1 phase
Scroll down to see optional tooling below.
This 100 ton is a popular machine because it is heavy, low priced, and can hold any two sets of tooling such as a punching head and pipe notcher or press brake and coper-notcher or 2 punching heads.
We also include a tool box of 8 round punch & die sets.
Optional pipe bender, roll bender or shop press attachment available.
Click to Request Our 100 ton Lower Discount Price and info packet
Edwards 120 Ton Hydraulic Ironworker
Photo shows orange cover over spare hydraulic spare cavity
Made in USA
- 11" throat, 9-1/8 open height, 1-1/8 stroke
- Punch 1-1/16" diameter through 1" thick steel plate
- 1-1/2 dia with oversize punch option
- Built in Shear cuts 1/2" x 24", 1" x 12", or 1-1/4 square or round
- Built in Angle Shear cuts 6 x 6 x 1/2 angle
- Built-in Coper-Notcher (3 x 6 x 1/2) included
- Spare hydraulic cavity to power extra set of tooling (see below)
- Quick cycle time of 2.5 seconds.
- Weight: 5500 pounds.
- Electrics: 10 HP, 220 Volts, 3 phase. Optional 440V or 575V
Scroll down to see optional tooling below.
We also include a tool box of 8 round punch & die sets.
Optional pipe bender, roll bender or shop press attachment available.
Click to Request Our 120 ton Lower Discount Price and info packet
Elite 110-65 Dual Operator 110 Ton Hydraulic Ironworker Machine
Made in USA
Super Dual Operator Ironworker Machine for heavy use
- 17.75" deep throat, 9-3/4 open height, 3" long stroke
- Punches up to 1-3/8 diameter thru 1" steel plate with oversize option or 4" dia thru 5/16" plate.
- Built in Shear cuts 3/8" x 24", or 1/2" x 14", or 1-1/4 square/round.
- Built in Angle Shear cuts 5x 5x 1/4 angle.
- Built-in Coper-Notcher (2.5 x 6 x 1/2) included
- Spare hydraulic cavity 11" wide for extra set of tooling such as press brake or pipe notcher.
This Dual Operator Machine has built in lighting, electric stroke control, hydraulic accessory ports (for pipe bender or hydraulic shop press), central lube system, UL listed controls and swing away stripper.
- Weight: 6000 pounds.
- Electrics: 7.5 HP, 220 Volts, 3 phase.
- Optional 440V or 575V or 220V, 1 phase
Scroll down to see optional tooling below.
We also include a tool box of 8 round punch & die sets
Powerlink Hydraulic Accessory Connector included with machines 55 ton and larger
Made in USA
The Powerlink allows you to easily plug in another machine to the hydraulic pump of your ironworker such as the pipe bender, 20 ton tabletop shop press, 40 ton shop press, radius rolling machine or the horizontal press brake. It is extremely difficult to install this option on an existing machine so it cannot be added to an existing machine.
Pipe Bender connects to your new Ironworker
Made in USA
This machine is usually in stock
Edwards Pipe Bender option requires the hose connection kit and labor at the factory to set up your newly purchased Ironworker machine to connect this pipe/tube bender
Available as a standalone with it's own hydraulic power unit for extra cost
- 2" (10) Schedule 40 Pipe Capacity
- 2-1/2" (00) .095" wall Tube Capacity
- 2-1/4" .083" Chromoly Capacity
- Die Sets Sold Separately ( click to see the huge list of die sets)
- Cylinder 1-3/4" ram
- Stroke 14"
- Heavy Duly All Steel Construction
- Smooth, Fast operation
- 180 Degree Bend Capacity
- Easy To Use Hand Controls
- Operates Horizontal or Vertically
- Heavy Duty Rolling and Locking Stand
- Auto Stop Feature For Repeatable Bends
- Quick Disconnect Hoses
20 Ton Shop Press connects to your new Ironworker
- Made in USA
- Heavy duty all steel constuction
- Easy to use hand controls
- Quick disconnect hoses
- Cylinder with 2" RAM, 6-1/4" stroke
- Width between frame columns: 20"
- Excellent Table Top Machine
The 20 ton Shop Press is an option that connects to your new Edwards ironworker machine with the optional hydraulic accessory connector
Optional Press Brake tooling available- 18" long (can bend 1/4 thick x 18" wide)
40 Ton Shop Press connects to your new Ironworker
- Made in USA
- Heavy duty all steel constuction
- Easy to use hand controls
- Quick disconnect hoses
- Cylinder with 4" RAM, 6" bore
- Stroke: 12-1/4"
- Width between frame columns: 40"
- Optional Press Brake Tooling as seen in photo is 32 inch long, can bend 3/16 x 32", 1/4 x 24", 3/8 x 6" wide
The 40 ton Shop Press is an option that connects to your new Edwards ironworker machine with the optional hydraulic accessory connector
Optional Press Brake tooling available- 12 inches long
- 18 inches long
- 24 inches long
- 32 inches long
Radius Rolling machine for pipe, tube, angle, flat bar
Just connect it to your Ironworker machine
Made in USA
Plug it into your Edwards Ironworker with the Hydraulic Accessory Connector or power it separately with an Edwards Porta-Power to expand your fabrication capabilities. The variable speed hydraulic drive allows you to dial in the appropriate speed for various materials. Quickly change the orientation from vertical for smaller projects to horizontal for those larger, heavier jobs. The machine includes a set of flat rolls standard.
Capacities:- Round Pipe: 2" schedule 40 (optional rolls required)
- Round Tube: 2.5" diameter with .095 wall thickness (optional rolls required)
- Round Bar: 1.375" diameter (optional rolls required)
- Square Tube: 2 inch with .12 wall thickness
- Flat Bar: 4 x .75" easy way / 3/8 x 2 hard way
- Angle Iron: 2 x 2 x 1/4
20 Ton Horizontal Press Brake connects to your new Ironworker machine
Made in USA. This machine comes with standard V-die tooling for simple bends but you can also put other different tooling shapes on the vertical shafts of this machine to form, bend, and straighten metal. This machine can quickly connect to your Edwards Ironworker with a Hydraulic Accessory Connector or an Edwards Porta-Power to expand the fabrication abilities of your shop. Designed for maximum tooling flexibility, the 4 pin locations are locked with a simple crank for inboard tool squaring. Digital encoder reads positive stop for accurate repeatability within 0.01". Stroke: 10 inches. Work height: 38 inches
Edwards Iron worker Tooling
Made in USA
Coper-Notcher, Angle-Notcher, Pipe Notcher, Press-Brake, Rod-Shear, Custom Channel-Shear, Spare Punching Assembly, Extra Large Punching Assembly, Quick Change Punch Coupling, Magnetic Bar Fence, Gaging Table, Pedestal Die Table, Picket making tooling and many sizes and styles of punch & die sets. Click to see a list of Punch and Die Set Sizes The 55 ton, 65 ton, 100 ton and 120 ton machines have a powered spare tooling station to use almost any of the tooling shown or to use your own custom die set without having to unbolt the punching head. Only the 55 ton and 100 ton Jaws IV ironworkers have the option of holding 2 punching assemblies simultaneously (1 on each side). Custom tooling also available.
SCROLL DOWN TO SEE THE TOOLING PICTURES Click to see VIDEOS of the Edwards Tooling
Coper-Notcher-Nibbler
Standard on 60, 65, 100 deluxe, 120 ton. Used for square, rectangular or angle V notching. Copes angle iron flanges.
Press-Brake
Has 4-way style lower die. Has V die openings for bending metal 1/16, 1/8, 3/16, and 1/4" thick. Can bend 3/8"
Pipe Notcher
Cuts pipe with a semi-circular cut to allow one pipe to fit 90deg against another for railings. Sizes from 1/2 to 2" pipe.
Vee Notcher
(3 x 3 V shaped notch up to 1/4 thick., but the Coper-Notcher also V notches)
Rod Shear
(shears 1/4, 3/8, 1/2, 5/8, 3/4, 1"diameter rod cleanly and quickly)
Pedestal Die Table
(for punching 2"angle iron leg down. Included with most ironworkers)
Large Gauging Table
(for attaching jigs, fixtures & fences. Choose from 3/8" thick or 1" thick)
Protractor Angle Gauge
Sets the pice part angle when shearing flat bar or when punching.
Urethane Stripper
Prevents distortion when punching soft aluminum, copper, brass, bronze, etc.
Adjustable Back Gauge
For setting repeat distances for punching holes, shearing angle and shearing flat bar.
Automatic Cut Back Gauge
For setting repeat distances for punching or shearing. Automatically cuts without stepping on foot pedal.
Electric Stroke Control
Saves time by shortening stroke when punching thin metal or to control upper press brake die for repeat bend angles.
Stripper Reducer
Minimizes distortion in thin metals when using smaller punches & dies
Oversize Punching Assembly
Includes oversize punch stem, nut, & die table for punching up to 1- 9/16" dia.
241 Large Punching Assembly
for punching up to 4"diameter. Can also be used for corner radius notching.
Rotating Turret
Allows use of Multiple Pipe Notchers
Back Gauge for press-brake
Measures the position of your bend
Box of Punch & Die Sets
Free set of 8 with most Ironworkers
