New Lathe Machines: Most of our lathes are in stock ready to ship.
One year warranty. Spare parts are quickly available from our warehouse.
Options Available:
2 axis Digital Readout

Taper Turning attachment
Micro Carriage Stop
5-C Lever Collet Closer

We are accedited by the Better Business Bureau! Click to verify A+ rating We accept credit cards for up to $10,000.

Birmingham YCL-1236 Lathe machine
Photo of Birmingham Lathe model YCL-1236GH
Click to request a quote YCL-12x36

12" swing x 36" center distance Precision Geared Head Gap Bench type including floor stand.
12" diameter x 36" center distance
7" diameter max swing over carriage
2 HP, 220 volt, 1 phase motor
9 speeds from 70 - 1400 RPM
Standard Equipment:
6" 3-jaw chuck 8" 4-jaw chuck
10" face plate 1-1/2" spindle bore
3 3/4" steady rest follow rest Gap
4-way tool post thread chasing dial
2 dead centers reducing sleave
full splash guard chip tray
automatic longitudinal and cross feeding
The machine and stands come in separate crates.

Birmingham YCL-1340 Lathe machine
Photo of Birmingham Lathe mchine
Click to request a quote YCL-13x40
SAME AS ABOVE EXCEPT:
13" swing x 40" center distance
8" diameter max swing over carriage

Birmingham YCL-1440 Gap Bed Tool Room Lathe Machine:
Picture of Birmingham YCL-1440 Precision Tool Rom Lathe
Click to request a quote YCL-14x40
14" swing x 40" center distance with base
1.5" spindle bore
16 speed, 3 HP, 220 volts, 3 phase.
8.62" diameter max swing over carriage
Standard Equipment:
6" 3-jaw chuck 8" 4-jaw chuck
12" face plate 3 3/4" steady rest
follow rest Gap 4-way tool post
thread chasing dial 2 dead centers
reducing sleave full splash guard chip tray
foot brake worklight coolant system
No manually changing out gears required for most threading

Birmingham YCL1640 & YCL1660 Lathe Machines
Image of Birmingham YCL-1660
Click for a quote YCL-1640 & YCL-1660
16" swing x 40" center distance
16" swing x 60" center distance
8.81" dia swing over carriage.
12 speed, 7.5 HP, 220 volts, 3 phase.
2 9/32" spindle bore.
Standard Equipment:
10" 3-jaw chuck 12" 4-jaw chuck
Cast iron base 14" face plate
7 1/2" steady rest follow rest
Gap 4-way tool post thread chasing dial
2 dead centers reducing sleave
full splash guard foot brake
worklight coolant system
No manually changing out gears required for threading

Birmingham 20, 22, 26 & 32 inch YCL Lathe Machines

Click to Request a Quote for 20 inch swing x 60 long: YCL-2060

Click to Request a Quote for 20 inch swing x 80 long: YCL-2080

Click to Request a Quote for 20 inch swing x 120 long: YCL-20120

Click to Request a Quote for 22 inch swing x 60 long: YCL-2260

Click to Request a Quote for 22 inch swing x 80 long: YCL-2280

Click to Request a Quote for 22 inch swing x 120 long: YCL-22120

Click to Request a Quote for 26 inch swing x 80 long: YCL-2680:

Click to Request a Quote for 26 inch swing x 120 long: YCL26120

Click to Request a Quote for 32 inch swing x 80 long: YCLL3280

Click to Request a Quote for 32 inch swing x 120 long: YCLL32120

The above sizes are usually in stock!.
Choose from 20", 22", 26" or 32" swing diameters
Choose from 60", 80" or 120" center distances.
12 speeds, 3-1/8" bore, 10 HP, 220V, 3ph.
20" has 11.87" dia swing over cross slide.
22" has 13.75" dia swing over cross slide.
26" has 17.5" dia swing over cross slide.
32" has 22.5" dia swing over cross slide.
Fully equipped!
Standard Equipment:
Cast iron base 12" 3-jaw chuck 16" 4-jaw chuck 18" face plate 10" drive plate steady rest follow rest removeable gap 4-way tool post thread chasing dial 2 dead centers reducing sleave
full splash guard foot brake coolant system
4 position auto carriage stop worklight
No manually changing gears required for threading
Normally in stock. Manufactured in China.

Lathe: Acra 1440TVS variable speed

ACRA High Precision Lathe Machine: 14 inch
High Quality Manufactured in Taiwan (not China)

Click to Request this Quote
Priced starting at $13,750 for 1440TE (brand new)
FREE Shipping to most of USA.
Models 1400TE (8 speeds) and 1400TVS (variable speed)
14" swing diameter
Choose 40" or 60" between centers
2-1/16" Diameter Spindle Bore
5 HP Motor, 220 or 440 Volts 3 phase electrics
8-3/8" diameter swing over cross slide

Standard Equipment:
• 8" 3-jaw chuck • 10" 4-jaw chuck
• Steady Rest • Follow Rest
• Coolant System • Halogen Light
• Full length splash guard • 4-way tool post
• Model 1400TVS: Yaskawa variable speed Inverter

Options Available:
• Face Plate • Micro Bed Stop • Chuck guard
• 5C Collet Closer • Quick change tool post
• Newall, Sino, Acu-Rite, or Fagor Digital Readout
• Taper Attachment

Lathe: ACRA 1640TVS variable speed

ACRA High Precision Lathe Machine: 16 inch
High Quality Manufactured in Taiwan (not China)

Click to Request this Quote
Priced starting at $15,850 for 1640TE (brand new)
FREE Shipping to most of USA.
Models 1600TE and 1600TVS (variable speed)
16" swing diameter
Choose 40" or 60" between centers
Choose 12 speed or variable speed
2-1/16" Diameter Spindle Bore
5 HP Motor, 220 or 440 Volts 3 phase electrics
10-3/8" diameter swing over cross slide

Standard Equipment:
• 8" 3-jaw chuck • 10" 4-jaw chuck
• Steady Rest • Follow Rest
• Coolant System • Halogen Light
• Full length splash guard • 4-way tool post
• Model 1600TVS: Yaskawa variable speed Inverter

Options Available:
• Face Plate • Micro Bed Stop • Chuck guard
• 5C Collet Closer • Quick change tool post
• Newall, Sino, Acu-Rite, or Fagor Digital Readout
• Taper Attachment
